Máy tạo dòng điện PI505
- Loại điều chỉnh bằng tay
- Hãng sản xuất: APT
- Bộ sản phẩm bao gồm:
- Modul: tạo dòng
- Modul: điều khiển
- Xuất xứ: trung quốc
- Bảo hành 12 tháng
Specifications:
- Digital Sampling & Measure, Digital Display
- Higher accuracy and resolution
- More reliable protections
- Auto timing
- Digital Sampling & Measure, Digital Display
- Higher accuracy and resolution
- More reliable protections
- Auto timing
- Lower cost
- High usability
- Portable, All-in-one.
Application:
- PI505 Single Phase 5000A Primary Current Injection is a new type with digital measure & display circuit. Such a configuration & design, making its test higher accuracy and resolution, more reliable protections and auto timing available, compared with traditional manual type,and automatic type, much lower cost, higher usability.
- In the field of its application, widely used for trip test of air circuit breaker, contactor, relay and so on.
Product Features:
- Two Separate units
- Equipped with digital measure circuit, high accuracy LCD meters
- Digital display with higher accuracy and resolution
- Auto timing
- Digital sampling make its protections more reliable
- Lower cost, higher usability, Low failure rate
- Small size ,easy to operate
Specifications:
- Input:380V±10%, 65A, 50Hz/60He
- Output
- Output Current 5000A, Accuracy: 0.5%,Resolution: 0.1A; Open circuit voltage:5V
- Capacity: 25KVA
- Timing range:0~999 seconds
- Duty Cycle: 5 minutes on, 10 minutes off at rated current output.
- Operating temperature: -10~40°C
- RH: ≤80%,no dew
- Insulation Resistance >2MΩ
- Leakage Current <3.5mA
- AC Withstand Test: 1500Vac/50Hz,1 minute, Shell & Grounding
- Dimensions:610×515×920mm for Control Module, 530mm×450mm×550mm for Injection
- Weight : 90Kg for Control Module, 180 Kg for injection test
- Output Current Cable: 1000mm2×2500mm, 2 pcs
