Bộ chỉnh lưu KEP VP-300 (300A)
Hãng sản xuất: KEP
Xuất xứ: Ukraine
Model: VP-300
Thông số kỹ thuật: Bộ chỉnh lưu KEP VP-300 (300A)
Dùng để làm tan giã các mối hàn đầu cáp và vỏ
Điện áp vào AC 3 pha 4 dây, V: 380±38
Tần số, Hz 50±1
Chu kỳ làm việc: ngắn hạn
Dòng điện ra max, A: 300
Cầu chì A: 320±10
Công suất kW, max: 115
Kích thước, mm, max: 480х350х200
Trọng lượng, kg, max : 35
Tuổi thọ trung bình 10 năm
Cung cấp bao gồm:
- Máy VP-300
- Cáp kết nối dài 20 m, tiết diện 35 mm2
- Bộ điều khiển
Diode rectifier VP-300 is designed for disintegration a soldered connection point where cable's lead vein is short-circuiting with the sheath.
The device is manufactured in an aluminium containing case, equipped with convenient carrying handles and a hinged lid. The case has a compartment for cable management and control unit bay. Protective grounding is connected to the device via the grounding bolt. The device features active cooling fans for effective cooling of power thyristors.
VP-300 is powered from the three-phase AC mains, which is supplied through a four-wire power cable. Neutral conductor should always be connected to the power supply as the control unit of the device is powered by the single-phase 220 V voltage.
Input current is controlled by the rotary handle of the current regulator. VP-300 also features an automatic fuse protection should the input current go over the limit of 320 A or power thyristors heat over 85 °C.
To make usage of the device even easier, VP-300 is supplied with a remote control, which could be used for switching on the input current.
- Technical Specifications
Characteristic Value Three-phase AC power supply voltage (4-wire connection layout), V 380±38 Power supply frequency, Hz 50±1 Duty cycle Short-term Maximum output current, A 300 Fuse latching current, A 320±10 Consumed power, kW, max 115 Dimensions, mm, max 480х350х200 Net weight, kg, max 35 Lifespan, years, avg 10
